Szafa ognioodporna na baterie litowo-jonowe, dwudrzwiowa, rozmiar XL 90 min 1200 x 600 x 1950 mm, z listwami zasilającymi

The 90 min fireproof cabinet is the ideal solution for safe storage and charging of lithium batteries. It protects the battery from fire, leaks and other hazards.

Made entirely of cold-pressed steel sheet with a thickness of 1/1.5 mm.

Insulation resistant to extreme temperatures up to 800 °C.

Internal finish with high resistance even to aggressive fumes.

Hydraulic closing of the door at an ambient temperature above 47°C.

The ventilation ducts are closed at a temperature of 70°C.

Lower catch bath (in accordance with the requirements of the EN14470 standard).

Possibility of charging the battery inside the cabinet - a cabinet equipped with mains sockets for charging.

Lithium-ion battery cabinet equipment:

4 storage levels, including 1 lower tub with truss,

Charging strips at each storage level, 6 sockets each

Grounding, leveling legs,

Strong steel handle along the entire length of the door,

Single-leaf right door*,

Non-sparking hinges,

Key lock,

Marking in accordance with ISO 3864,

Construction allowing replacement of spare parts if necessary,

Optionally, the cabinet can be equipped with a fan or filter fan in a standard version, or EX/ATEX.

*The offer also includes a wardrobe with a left door. Contact us for more information.

The cabinet can be retrofitted with an automatic extinguishing system, which provides even greater safety when charging lithium-ion batteries. In models with an integrated fire extinguishing system, when a fire is detected, it is automatically activated and the extinguishing action begins.

Double protection: from the outside and from the inside

This fire-resistant cabinet for lithium-ion batteries complies with two separate safety standards — each of which protects against a different hazard. CHA

EN 14470-1 certificate — protection against external fire

The EN 14470-1 standard confirms that the cabinet can withstand exposure to fire from the surrounding environment (e.g. a fire in a hall or warehouse) for a specified period of time — our cabinets for 90 minutes. This provides a realistic time window for evacuation and fire-fighting operations, during which the batteries stored in the cabinet remain safe.

VDMA 24994 test — fire protection from the inside

VDMA 24994 is a test specifically designed for lithium-ion batteries. What happens if the battery itself fails and causes uncontrolled overheating (known as ‘thermal runaway’) inside the cabinet? The test result is clear-cut: pass or fail.

Our cabinet passed this test successfully: during a controlled test, a cell inside the chamber caught fire and exploded, and yet:

• no flames appeared on the outside,
• the temperature of the external walls remained within safe limits,
• the fire did not spread to the other batteries in the cupboard,
• The door’s structure and locks remained intact.

What does this mean for you?

By choosing a cabinet that has been tested to both standards, you benefit from protection in both respects:

• EN 14470-1 — Your batteries are safe, even if a fire breaks out nearby.
• VDMA 24994 — Your staff and the building are safe, even if a fire breaks out inside the battery itself.
